的主要用途是什么与详细资料：Purpose and introduction

该主设备使在对30-500ML系列作品玻离瓶、橡胶制品瓶的包装工作线封好。适用过往过往式活塞杆采取包装工作线，电滋振荡器送盖，可能轧盖(五金式)或旋盖(橡胶制品盖)封好，可能和左右侧的工作道工序主设备连接 形成工作线，不仅可能够买百级层流罩。This machine is suitable for the filling and sealing of 30-500ml series glass bottles and plastic bottles. The reciprocating between piston filling, electromagnetic oscillation send cover, cover (metal) can be rolled or screw cap (plastic cap) sealing. Can produce and the produce of the process equipment before and after connecting line. In addition, the laminar flow hood is available for selection.

优势：characteristic

装量最准，杜尽滴漏问题。缺瓶不罐装。 定频调速器。 被动表示数值的功效。 整个机器均按GMP符合要求设计制作。The filling amount is accurate, as Du drip. Lack of bottle does not fill. Frequency control of motor speed. Active display count. The machine according to the GMP request design.

工艺参数指标/technical parameters：

型号 model	NQGX30-500
适用性型号Cutting dimension	30-500ml
原产作用Production capacity	80-200瓶/分（罐/半小时）80-200 bottles/min (cans/min)
包装精确度 Filling accuracy	≤±1%
外接电源 Power	380V/50Hz
旋（轧）盖率Spin (rolling) cover rate	≥99%
功率power	3.0 kw
机械性净含量 Machine weight	1500 kg
外形尺寸 boundary dimension	3000*1100*1700mm
